Description
|
System hardware configuration:
|
|||||
|
Type
|
Details
|
Descriptions
|
|||
|
CPU |
Type
|
quad-core ARM Cortex-A55 (Amlogic S905X4)
|
|||
|
Speed
|
2.0GHz
|
||||
|
GPU
|
Type
|
G31 GPU
|
|||
|
RAM
|
Capacity
|
2GB/4GB(optional)
|
|||
|
ROM
|
EMMC
|
16GB/32GB/64GB/128GB(optional)
|
|||
|
Network Connections:
|
|||||
|
Type
|
Details
|
Descriptions
|
|||
|
WIFI
|
WIFI module
|
IEEE 802.11 a/b/g/n/ac（2.4G/5GH）+BT4.1
|
|||
|
Ethernet Network
|
RJ45
|
RJ45 10/100M
|
|||
|
Interface Configuration:
|
|||||
|
Type
|
Details
|
Descriptions
|
|||
|
Memory card socket
|
External memory
|
Support SDSC/SDHC/SDXC
|
|||
|
USB interface
|
Data transfer supportive
|
USB2.0x1 USB3.0x1
|
|||
|
AV jack
|
AV output
|
∮ 3.5mm standard jack
|
|||
|
DC connector
|
Power
|
∮5.5 mm
|
|||
|
HD interface
|
Audio/Video output
|
HD2.1
|
|||
|
Type C
|
N/A
|
||||
|
SPIDF jack
|
Audio output
|
Optical
|
|||
|
Keyboard
|
Input device
|
USB device
|
|||
|
Mouse
|
Input device
|
USB device
|
|||
|
Remote Control
|
Input device
|
IR Remote/2.4GHz Wireless Remote Controlle(optional)
|
|||
|
Necessary Accessories:
|
|||||
|
Type
|
Details
|
Descriptions
|
|||
|
Power adapter
|
Standard Configuration
|
∮5.5 mm DC 5V@2A
|
|||
|
Software Configuration:
|
|||||
|
Type
|
Details
|
Descriptions
|
|||
|
Operating System
|
Operating system version
|
Android 10.0
|
|||
|
Video Decoder |
AV1 MP-10@L5.1 up to 4Kx2K@60fps,VP9 Profile-2 up to 8Kx4K@24fps, H.265 HEVC MP-10@L5.1 up to 8Kx4K@24fps, AVS2-P2 Profile up to
4Kx2K@60fps, H.264 AVC HP@L5.1 up to 4Kx2K@30fps , H.264 MVC up to 1080P@60fps, MPEG-4 ASP@L5 up to 1080P@60fps (ISO-14496), WMV/VC-1 SP/MP/AP up to 1080P@60fps, AVS-P16(AVS+) /AVS-P2 JiZhun Profile up to 1080P@60fps, MPEG-2 MP/HL up to 1080P@60fps (ISO-13818), MPEG-1 MP/HL up to 1080P@60fps (ISO-11172), RealVideo 8/9/10 up to 1080P@60fps |
||||
|
Audio Decoder
|
Supports MP3, AAC, WMA, RM, FLAC, Ogg and programmable with 7.1/5.1 down-mixing
|
||||
